Scaling Analog Input S7 1200 vs S7 300

Understanding scaling the analog input is extremely important. So, this video provides a full explanation about scaling process using S7 1200/1500 vsS7300/400 Example: Monitor the Analog current 0 -50 A using : 1- PLC-Siemens 2- Current sensor with output 0 -10 volts _________________________________________________ Scaling Analog Input S7 1200&1500 1- Check the Analog Input Address 2- Use Norm and Scale Functions to get the input in Physical unit 2-1 Norm Function is used to convert the Digital Value of ADC 0-27648 to Real Number 0-1 2-1 Scaling Function is used to convert the output of Norm Function to the Physical Number 0 - 50 volts _________________________________________________ Scaling Analog Input S7 300&400 1- Check the Analog Input Address 2- Use Scale Function to get the input in Physical unit Scale Function is used to convert the Digital Value of ADC 0-27648 directly to Physical Number 0-50 volt
